A-7
Appendices
NJ-series Instructions Reference Manual (W502)
A-1 Error Codes Related to Instructions
App
Data Movement Instruc-
tions
Clear Initialize ---
Copy**ToNum (Bit String to
Signed Integer)
Bit Pattern Copy (Bit String to Signed
Integer) Group
---
Copy**To*** (Bit String to Real
Number)
Bit Pattern Copy (Bit String to Real
Number) Group
---
CopyNumTo** (Signed Integer
to Bit String)
Bit Pattern Copy (Signed Integer to Bit
String) Group
---
CopyNumTo** (Signed Integer
to Real Number)
Bit Pattern Copy (Signed Integer to Real
Number) Group
---
Copy**To*** (Real Number to
Bit String)
Bit Pattern Copy (Real Number to Bit
String) Group
---
Copy**ToNum (Real Number
to Signed Integer)
Bit Pattern Copy (Real Number to
Signed Integer) Group
---
Shift Instructions AryShiftReg Shift Register 16#0407
AryShiftRegLR Reversible Shift Register 16#0407
ArySHL Array N-element Left Shift 16#0407
ArySHR Array N-element Right Shift 16#0407
SHL N-bit Left Shift ---
SHR N-bit Right Shift ---
NSHLC Shift N-bits Left with Carry 16#0407
NSHRC Shift N-bits Right with Carry 16#0407
ROL Rotate N-bits Left ---
ROR Rotate N-bits Right ---
Conversion Instructions Swap Swap Bytes ---
Neg Reverse Sign ---
Decoder Bit Decoder 16#0406
Encoder Bit Encoder 16#0406
BitCnt Bit Counter ---
ColmToLine_** Column to Line Conversion Group 16#0405
16#0406
LineToColm Line to Column Conversion 16#0405
16#0406
Gray Gray Code Conversion 16#0400
16#0401
PWLApprox Broken Line Approximation 16#0401
16#0402
16#0406
MovingAverage Moving Average 16#0400
16#0406
PIDAT PID with Autotuning 16#0400
16#0401
DispartReal Separate Mantissa and Exponent 16#0402
UniteReal Combine Real Number Mantissa and
Exponent
---
NumToDecString Fixed-length Decimal Text String
Conversion
16#0400
16#0406
NumToHexString Fixed-length Hexadecimal Text String
Conversion
16#0400
16#0406
Type Instruction Name Error codes
