Section 2 NS Series Functions 2-6 Fixed Objects
2-63
NS Series Programming Manual
No. Setting Details
5 Chamfer Set a bevel.
Type
Select one of the following three bevel choices.
None: No bevel
Radius of curve: Rounds the corners using the bevel size setting for the radius.
Cut: Cuts off an isosceles triangle from each corner based on the bevel size setting.
Size
Specify the bevel size.
N
N
N
o
o
o
t
t
t
e
e
e
♦
Only shade settings can be made for polygons and sectors.
