Section 2 NS Series Functions 2-11 Multifunction Objects
2-194
NS Series Programming Manual
N
N
N
o
o
o
t
t
t
e
e
e
♦
Functional object ID numbers can be checked by selecting View – Show ID (click on Show ID) or
opening the Functional Object Properties Dialog Box.
>=>=
Specify the 4-digit number displayed here if using Specified Input Field to specify the ID number.
(In the above example, “7” is specified.)
Refer to Create Screens in the CX-Designer Online Help for information on ID displays.
♦
Set Input Field with Focus to transmit to other screens. Data cannot be transmitted even if the ID
number is set under Specified Input Field.
♦
A backslash will be sent if a yen symbol is specified as one of the characters to be sent.
♦
Focus is not moved to input-prohibited objects for focus control codes.
♦
If there are two input objects at an equal distance from the current object, the focus will move to
the object created first on the CX-Designer.
1
2
In this example, it is assumed that object 2 is
created earlier than object 1 on CX- Designer.
Current focus
Focus moved
using F UP.
Focus moves to object 2.
♦
Press a functional object other than a Command Button to which Key Button is set to remove focus
from numeral display and input objects and string display and input objects.
♦
To use S PAGEUP, S PAGEDOWN, S LINEUP or S LINEDOWN, select Specified Input Field as
the Transmit to Option and specify the ID number for list selection.
