Section 2 NS Series Functions 2-11 Multifunction Objects
2-215
NS Series Programming Manual
N
N
N
o
o
o
t
t
t
e
e
e
♦
The Multifunction Object processing will be canceled if there is no Video Board
mounted on the NS.
♦
Execute Video Control – Vision Sensor Console Output as the last function for touch ON timing.
♦
Video Control – Vision Sensor Console Output can be used only once for each Multifunction
Object.
1
No. Item Details
1 Signal type Sets the type of signal to be sent to the Vision Sensor.
Scroll Object
Scroll bars on functional objects can be operated from Multifunction Objects. The functional object is
scrolled in the specified direction for the specified amount.
Executable from Multifunction Objects
Scroll down
Scroll up
Scroll left
Scroll right
To Next Page
