Section 2 NS Series Functions 2-11 Multifunction Objects
2-221
NS Series Programming Manual
Buzzer
The Buzzer function is used to sound and stop the buzzer. Press the Special Button and select Buzzer
from the list that is displayed.
1
No. Item Details
Action Sets the control operation for the buzzer function.
Stop Buzzer Stops the buzzer that is currently sounding.
Any ON bit at $SB12 (continuous buzzer), $SB13 (short intermittent), or
$SB14 (long intermittent) will turn OFF.
Continuous
Buzzer
Sounds a continuous buzzer.
$SB12 will turn ON.
Short Inter-
mittent Buzzer
Sounds a short intermittent buzzer.
$SB13 will turn ON.
1
Long Inter-
mittent Buzzer
Sounds a long intermittent buzzer.
$SB14 will turn ON.
To Next Page
