Section 2 NS Series Functions 2-12 Display and Input Objects
2-266
NS Series Programming Manual
General Tab Page
Set the functions for the temporary input object.
1
2
No. Setting Details
1
Object
Comment
Sets an explanatory comment for the pasted object. (Up to 32 characters.)
2 Functions Sets the functions for the temporary input object.
Temporary
input
Displays the numeric value or character string input by the user when input focus is on
the numeral display and input object or string display and input object.
Show the
maximum
value
Displays the set upper limit for input when input focus is on numeral display and input
object or string display and input object.
Show the
minimum
value
Displays the set lower limit for input when input focus is on numeral display and input
object or string display and input object.
Text Attribute Tab Page
Sets the text attributes, such as font and color, for the display numerals or string. Refer to Tex t At t r ib-
utes under 2-8 Common Functional Object Functions for details.
Background Tab Page
Sets the background color for functional objects. Refer to Setting Colors under 2-8 Common Functional
Object Functions for details.
Frame Tab Page
Specify the colors and sizes of the object frame to change the shape or color when the button is de-
pressed or raised. Refer to Frames under 2-8 Common Functional Object Functions for details.
Size/Position Tab Page
Displays and sets the functional object size and position. Refer to Size/Position under 2-8 Common
Functional Object Functions for details.
To Next Page
