Section 2 NS Series Functions 2-18 System Clock
2-411
NS Series Programming Manual
No. Setting Details
5
Use Large
keypad
Select
Use Large keypad to use a large Settings Dialog Box (keypad). A 252 × 268 dot
(V
× H) keypad will be displayed during PT operation.
Text Attributes Tab Page
Sets the text attributes, such as font and color, for the time display. Refer to Text Attribute under 2-8
Common Functional Object Functions for details.
Frame Tab Page
Specifies the colors and sizes of the object frame to change the shape or color when the button is de-
pressed or raised. Refer to Frames under 2-8 Common Functional Object Functions for details.
Background Tab Page
Sets the background color for time display from a selection of 256 colors. Refer to Background under
2-8 Common Functional Object Functions for details.
Flicker Tab Page (Extension Tab)
Makes flicker settings to make the object flicker (flash). Refer to Flicker under 2-8 Common Functional
Object Functions for details.
Write (Extension Tab)
The write operation can be confirmed using the dialog box before the time is set. The confirmation
message can be changed. Refer to Write Settings under 2-8 Common Functional Object Functions for
details.
Password Tab Page (Extension Tab)
A password can be set for when the object area is pressed. Five passwords of up to 16 characters
each can be set. One password can be requested for each object. Refer to Passwords under 2-8
Common Functional Object Functions for details.
Control Flag Tab Page (Extension Tab)
Control flags control the input and display of functional objects. Use control flags to enable display or
input when the contents of an address turn ON or OFF. Refer to Control Flags under 2-8 Common
Functional Object Functions for details.
Size/Position Tab Page (Extension Tab)
Sets the functional object size and position. Refer to Size/Position under 2-8 Common Functional Ob-
ject Functions for details.
To Next Page
