When a function block help file is imported, the following Import Dialog Box is displayed.
If you select a help file (.pdf extension) with the same name as the imported function block, the
specified file is copied to the save location for the user-defined help file.
A dialog box to check the CRC data is displayed.
3 Check the CRC data, and click the OK Button.
The function block is imported and added to the project.
Precautions for Correct Use
After a function block is imported, the Safety CPU Unit will be in an unvalidated state. Always
execute safety validation again.
Additional Information
You can check the CRC data on the Change Tracking T
ab Page or Properties Dialog Box.
6 Programming
6 - 34
NX-series Safety Control Unit User's Manual (Z930)
