Omron NX-SID Series - Page 485

A - 85
Appendix
NX-series Safety Control Unit User’s Manual (Z930)
A-13 Execution Scenarios for the Simple
Automatic Test
A
1. Initialization
2. Shutoff Test
3. Return Test (Reset Type: Auto)
4. Return Test (Reset Type: Manual)
<1-1>
<1-2>
<1-3>
<1-4>
Reset variable
All registered input
variables
All registered output
variables
<2-1>
<2-2>
<2-3>
Target input variable
Output Variables
expected to be 0
Output variables
expected to be 1
<3-1>
<3-2>
Target input variable
All registered output
variables
<4-1>
<4-2>
<4-3>
<4-4>
<4-5>
<4-5>
Target input variable
Reset variable
Output variables
expected to be 0
Output variables
expected to be 1
