10 Sample Programming
10-18
NJ/NX-series CPU Unit Motion Control User’s Manual (W507)
// If the external button is ON (i.e., if ResetOn changes to TRUE) while there is a minor fault level error,
// the MC_Reset (Reset Axis Error) instruction is executed.
IF (MC_Axis000.MFaultLvl.Active=TRUE)
AND (ResetOn=TRUE) THEN
Reset_Ex := TRUE; // Minor fault is reset.
ELSE
Reset_Ex := FALSE;
END_IF;
// If the Failure output variable from the MC_Reset instruction changes to TRUE,
// processing is performed to read the cause of the error with GetFaultFactor.
// Program GetFaultFactor according to the device.
IF (MC_Axis000.MFaultLvl.Active=TRUE)
AND (Reset_Fail=TRUE) THEN
GetFaultFactor();
END_IF;
// If a minor fault level error did not occur or was reset,
// normal device processing (RegularProcess) is performed.
// Program GetFaultFactor according to the device.
IF MC_Axis000.MFaultLvl.Active=FALSE THEN
RegularProcess();
END_IF;
// MC_Reset
RESET(
Axis := MC_Axis000,
Execute := Reset_Ex,
Done => Reset_D,
Busy => Reset_Bsy,
Failure => Reset_Fail,
Error => Reset_Err,
ErrorID => Reset_ErrID
);
ST Programming
