Omron NX701-1 User Manual

4 Checking Wiring from the Sysmac Studio
4-2
NJ/NX-series CPU Unit Motion Control User’s Manual (W507)
4-1 Functions of the Sysmac Studio
This section describes how to use the MC test run function to check wiring and basic settings. You can
use the MC test run function in the Sysmac Studio to check wiring without any programming.
The MC test run operation supports the following functions.
4-1-1 MC Test Run Function
Category
Function Description Setting/monitor item
Axis operation Deceleration
stop
A deceleration stop is performed during the MC
Test R un.
---
Servo
ON/OFF
The Servo is turned ON and OFF. ---
Resetting
errors
The errors in the MC Function Module are
reset.
---
Jogging Jogging is performed in the positive or negative
direction.
Target Velocity
Acceleration/Deceleration
Absolute posi-
tioning
Absolute positioning is performed.
*
Target Position
Target Velocity
Acceleration/Deceleration
Jerk
Relative posi-
tioning
Relative positioning is performed. Travel Distance
Target Velocity
Acceleration/Deceleration
Jerk
Homing Homing is performed using the homing parame-
ter settings.
Homing Parameters
