1 Introduction to the Motion Control Function Module
1-4
NJ/NX-series CPU Unit Motion Control User’s Manual (W507)
Version Information
A CPU Unit with unit version 1.05 or later and Sysmac Studio version 1.06 or higher are required
to use the NX-series Position Interface Units.
The Position Interface Unit and Sysmac Studio are used for the MC Function Module.
 Position Interface Unit
The MC Function Module uses the Position Interface Units to output motor control pulses and read
encoder inputs.
 Sysmac Studio
The Sysmac Studio is connected to the built-in EtherNet/IP port on the CPU Unit with an Ethernet
cable.
Precautions for Correct UsePrecautions for Correct Use
Some of the functions of the MC Function Module are different when NX-series Position Inter-
face Units are used. Refer to the NX-series Position Interface Units User’s Manual (Cat. No.
W524) for details.
Motion Control Configuration on CPU Unit
Sysmac Studio
EtherNet/IP
LAN
Encoder
G5-series Servo Drives
NX1P2
Built-in EtherNet/IP port
Position Interface Units
