Omron Varispeed E7 User Manual

User Parameter Tables
5-9
DC Injection Braking: b2
b1-11 RUN delay
Sets the delay time for the execu-
tion of the Run signal. During the
delay the Digital Operator display
will show “ddLY”
0 to
600
0 sec. No A 1DFH –
b1-12
HAND fre-
quency reference
source selection
*1
Sets the source of frequency refer-
ence for HAND operation.
0: Digital Operator
1: Control Circuit Terminal (ana-
log input)
0 or 1 0 No A 1E0H 6-61
b1-13
HAND/AUTO
switching during
Run selection
*1
Selects if the Inverter will permit
switching between HAND and
AUTO Modes while running.
0: Disabled
1: Enabled
0 or 1 0 No A 61DH 6-61
b1-14
Emergency over-
ride speed
Sets the frequency reference used
in emergency override mode when
b1-15=0.
0.00 to
200.0
0.00
Hz
No A 61AH 6-108
b1-15
Emergency over-
ride reference
selection
Selects the emergency override ref-
erence source.
0: Use b1-14 as frequency refer-
ence
1: Use AUTO as frequency refer-
ence
0 or 1 0 No A 61BH 6-108
*1. This parameter is effective only, when the HOA operator JVOP-162 is used.
Param-
eter
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Access
Level
MEMO-
BUS
Register
Page
b2-01
DC injection
braking start fre-
quency
Used to set the frequency at which
DC injection braking starts in units
of Hz when b1-03 is set to 0 (decel-
eration to stop).
If b2-01 < E1-09 (Min. output
freq.) then DC injection begins at
E1-09.
0.0 to
10.0
0.5 Hz No A 189H 6-13
b2-02
DC injection
braking current
Sets the DC injection braking cur-
rent as a percentage of the Inverter
rated current.
0 to
100
50% No A 18AH
6-11
6-13
b2-03
DC injection
braking time at
start
Sets the time DC injection braking
is performed before the Inverter
starts to accelerate the motor.
Used to stop a coasting motor
before restarting it.
A set value of 0 sec. disables DC
injection braking at start.
0.00
to
10.00
0.00
sec.
No A 18BH 6-13
b2-04
DC injection
braking time at
stop
Sets the time DC injection braking
is performed after finished deceler-
ation.
Used to prevent coasting at the end
of deceleration.
A set value of 0 sec. disables DC
injection braking at stop
0.00
to
10.00
0.50
sec.
No A 18CH
6-11
6-13
Param-
eter
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Access
Level
MEMO-
BUS
Register
Page
