Omron Varispeed E7 User Manual

Individual Functions
6-79
0015H
Fault Content 2
Bit 0 EF3, External fault set on terminal S3
Bit 1 EF4, External fault set on terminal S4
Bit 2 EF5, External fault set on terminal S5
Bit 3 EF6, External fault set on terminal S6
Bit 4 EF7, External fault set on terminal S7
Bit 5 Not used
Bit 6 Not used
Bit 7 Not used
Bit 8 Not used
Bit 9 Not used
Bit A PF, Input phase loss
Bit B LF, Output open phase
Bit C OH3, Motor overheat pre-alarm (PTC analog input)
Bit D OPR, Digital operator disconnected
Bit E ERR, EEPROM fault
Bit F OH4, Motor overheat (PTC analog input)
0016H
Fault Content 3
Bit 0 CE, Memobus communications error
Bit 1 BUS, Bus option communications error
Bit 2/3 Not used
Bit 4 Not used
Bit 5 Not used
Bit 6 EF0, External fault from optional input card
Bit 7 FBL, PI feedback loss
Bit 8 LL3, Loss of Load detection
Bit 9 Not used
Bit A OL7, High Slip Braking overload
Bit B to F Not used
0017H
CPF Fault Content 1
Bit 0/1 Not used
Bit 2 CPF02
Bit 3 CPF03
Bit 4 Not used
Bit 5 CPF05
Bit 6 CPF06
Bit 7 to F Not used
0018H
CPF Fault Content 2
Bit 0 CPF20
Bit 1 CPF21
Bit 2 CPF22
Bit 3 CPF23
Bit 4 to F Not used
