Individual Functions
6-89
Monitor Items (U1-)
Multi-Function Digital Inputs (H1-01 to H1-05)
Multi-Function Analog Input (H3-09)
Parameter
Number
Name
Output Signal Level
at Analog Output
Unit
U1-24 PI feedback value 10 V: 100% feedback 0.01%
U1-36 PI input volume 10 V: 100% PI input 0.01%
U1-37 PI output volume 10 V: 100% PI output 0.01%
U1-38 PI setpoint 10 V: 100% PI target 0.01%
U1-53 PI feedback 2 10 V: 100% PI feedback 0.01%
Set Value Function
19 PI control disable (ON: PI control disabled)
30 PI control integral reset (ON: integral reset and hold as long as input is ON)
31 PI control integral hold (ON: integral is hold)
34 PI soft starter disable (ON: disabled)
35 PI input characteristics switch
Set Value Function
B PI feedback
C PI target value
16 PI differential feedback
