User Parameters
10-7
b5-10 PI output gain 1.0
b5-11 PI reverse output selection 0
b5-12 Selection of PI feedback loss detection 0
b5-13 PI feedback loss detection level 0%
b5-14 PI feedback loss detection time 1.0 sec.
b5-15 Sleep function operation level 0.0 Hz
b5-16 Sleep operation delay time 0.0 sec.
b5-17 Acceleration/deceleration time for PI reference 0.0 sec.
b5-18 PI setpoint selection 0
b5-19 PI setpoint 0.0%
b5-20 PI setpoint scaling 1
b5-21 Sleep function selection 1
b5-22 Snooze level 0%
b5-23 Snooze delay time 0 sec
b5-24 Wake-up level 0%
b5-25 Setpoint boost 0%
b5-26 Maximum boost time 0 sec
b5-27 Snooze feedback 60%
b5-28 PI feedback square root operation 0
b5-29 PI feedback square root gain 1.00
b5-30 PI output monitor square root 0
b5-31 PI unit selecction
0
*1
b8-01 Energy-saving mode selection 0
b8-04 Energy-saving coefficient
288.20
*2
b8-05 Power detection filter time constant 20 msec.
b8-06 Search operation voltage limiter 0%
C1-01 Acceleration time 1 10.0 sec.
C1-02 Deceleration time 1 10.0 sec.
C1-03 Acceleration time 2 10.0 sec.
C1-04 Deceleration time 2 10.0 sec.
C1-09 Emergency stop time 10.0 sec.
C1-11 Accel/decel time switching frequency 0.0 Hz
C2-01 S-curve characteristic time at acceleration start 0.20 sec.
C2-02 S-curve characteristic time at acceleration end 0.20 sec.
C4-01 Torque compensation gain 1.00
C4-02 Torque compensation time constant
200 msec.
C6-01 Normal duty selection 1
C6-02 Carrier frequency selection
6
*3
C6-03 Carrier Frequency Upper Limit
15 kHz
*2
C6-04 Carrier Frequency Lower Limit
15 kHz
*2
C6-05 Carrier Freq. Proportional Gain 00
No. Name
Factory
Setting
Setting
