Omron Varispeed E7 User Manual

10-8
d1-01 Frequency reference 1 0.00 Hz
d1-02 Frequency reference 2 0.00 Hz
d1-03 Frequency reference 3 0.00 Hz
d1-04 Frequency reference 4 0.00 Hz
d1-17 Jog frequency reference 6.00 Hz
d2-01 Frequency reference upper limit 100.0%
d2-02 Frequency reference lower limit 0.0%
d2-03 Master speed reference lower limit 0.0%
d3-01 Jump frequency 1 0.0 Hz
d3-02 Jump frequency 2 0.0 Hz
d3-03 Jump frequency 3 0.0 Hz
d3-04 Jump frequency width 1.0 Hz
d4-01 Frequency reference hold function selection 0
d4-02 Trim control level 10%
E1-01 Input voltage setting
200 V
*4
E1-03 V/f pattern selection F
E1-04 Max. output frequency 50.0 Hz
E1-05 Max. output voltage
200.0 V
*4
E1-06 Base frequency 50.0 Hz
E1-07 Mid output frequency
2.5 Hz
E1-08 Mid. output frequency voltage
15.0 V
*4
E1-09 Min. output frequency 1.2 Hz
E1-10 Min. output frequency voltage
9.0 V
*4
E1-11 Mid. output frequency 2
0.0 Hz
E1-12 Mid. output frequency voltage 2
0.0 V
E1-13 Base voltage
0.0 V
E2-01 Motor rated current
1.90 A
*2
E2-03 Motor no-load current
1.20 A
*2
E2-05 Motor line-to-line resistance
9.842Ω
*2
F6-01 Operation selection after communications error 1
F6-02 Option card external fault detection selection 0
F6-03 Option card external fault stopping method 1
F6-05 Current scaling via communication option card 0
H1-01 Terminal S3 function selection 24
H1-02 Terminal S4 function selection 14
H1-03 Terminal S5 function selection
3 (0)
*5
H1-04 Terminal S6 function selection
4 (3)
*5
H1-05 Terminal S7 function selection
6 (4)
*5
H2-01 Terminal M1-M2 function selection 0
H2-02 Terminal M3-M4 function selection 1
No. Name
Factory
Setting
Setting
