User Parameters
10-9
H3-02 Terminal A1 gain 100.0%
H3-03 Terminal A1 bias 0.0%
H3-08 Analog input A2 signal level selectoin 2
H3-09 Analog input A2 function selection
2
*6
H3-10 Terminal A2 gain 100.0%
H3-11 Terminal A2 bias 0.0%
H3-12 Analog input filter time constant 0.30 sec.
H3-13 Terminal A1/A2 switching 0
H4-01 Terminal FM monitor selection 2
H4-02 Terminal FM gain 100%
H4-03 Terminal FM bias 0.0%
H4-04 Terminal AM monitor selection 8
H4-05 Terminal AM gain 50%
H4-06 Terminal AM bias 0.0%
H4-07 Terminal FM signal level selection 0
H4-08 Terminal AM signal level selection 0
H5-01 Station address 1F
H5-02 Communications speed selection 3
H5-03 Communications parity selection 0
H5-04 Stopping method after communications error 3
H5-05 Communications error detection selection 1
H5-06 Send wait time 5 msec.
H5-07 RTS control ON/OFF 1
H5-08 Communications Selection 0
H5-09 CE detection time 2.0 sec.
L1-01 Motor protection selection 1
L1-02 Motor protection time constant 1.0 min
L1-03 Alarm operation selection during motor overheating 3
L1-04 Motor overheating operation selection 1
L1-05 Motor temperature input filter time constant 0.20 sec.
L2-01 Momentary power loss detection 0
L2-02 Momentary power loss ride through time
0.1 sec.
*2
L2-03 Min. baseblock time
0.1sec.
*2
L2-04 Voltage recovery time
0.3 sec
*2
L2-05 Undervoltage detection level
190 V
*4
L3-01 Stall prevention selection during acceleration 1
L3-02 Stall prevention level during acceleration 120%
L3-04 Stall prevention selection during deceleration 1
L3-05 Stall prevention selection during running 1
L3-06 Stall prevention level during running 120%
L4-01 Speed agreement detection level 0.0 Hz
No. Name
Factory
Setting
Setting
