Omron Varispeed E7

User Parameters
10-11
o2-10 Fan operation time setting 0 hrs.
o2-12 Fault trace initialize 0
o2-14 kWh monitor initialize 0
o2-15 HAND key function selection 1
o2-17 Standard / IP54 Selection
*7
o3-01 Copy function selection 0
o3-02 Read permission selection 0
T1-02 Motor output power
0.40 kW
*2
T1-04 Motor rated current
1.90 A
*2
*1. Parameter function is only valid if a Digital Operator with LCD clear text display is used (LCD or HOA Digital Operator)
*2. The factory setting depends on the Inverter capacity.
*3. The factory setting depends on the Inverter capacity and the protection class.
*4. Values for 200 V class Inverters are shown. For a 400 V class Inverter the values have to be doubled.
*5. The values in parentheses indicate initial values when initialized in 3-wire-sequence.
*6. Setting switched to “B” when PI controller is enabled
*7. The setting depends on the protection class of the Inverter.
No. Name
Factory
Setting
Setting
