ZS3-4 Controller Hardware Overview
Slot
Mfg Part
Number
Description Max Note
2 7070006 2-port 10Gb Ethernet Copper
NIC
4 Optional recommended front-
end
2 375-3696-01 2-port InfiniBand CX2 HCA 4 Optional recommended front-
end
2 7070195 4-port 1Gb Ethernet Copper
UTP NIC
4 Optional recommended front-
end
2 7051223 2-port 10Gb Ethernet Optical
NIC
6 Optional recommended front-
end
2 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or initiator
(backup)
2 7023303 2-port 16Gb FC HBA 4 Optional FC target or initiator
(backup)
3 7070006 2-port 10Gb Ethernet Copper
NIC
4 Optional recommended front-
end
3 375-3696-01 2-port InfiniBand CX2 HCA 4 Optional recommended front-
end
3 7070195 4-port 1Gb Ethernet Copper
UTP NIC
4 Optional recommended front-
end
3 7051223 2-port 10Gb Ethernet Optical
NIC
6 Optional recommended front-
end
3 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or initiator
(backup)
3 7023303 2-port 16Gb FC HBA 4 Optional FC target or initiator
(backup)
4 7070006 2-port 10Gb Ethernet Copper
NIC
4 Optional recommended front-
end
4 375-3696-01 2-port InfiniBand CX2 HCA 4 Optional recommended front-
end
4 7070195 4-port 1Gb Ethernet Copper
UTP NIC
4 Optional recommended front-
end
4 7051223 2-port 10Gb Ethernet Optical
NIC
6 Optional recommended front-
end
4 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or initiator
(backup)
4 7023303 2-port 16Gb FC HBA 4 Optional FC target or initiator
(backup)
C 511-1496-05 Cluster Controller 200 1 Cluster base configuration
5 7070006 2-port 10Gb Ethernet Copper
NIC
4 Optional recommended front-
end
5 375-3696-01 2-port InfiniBand CX2 HCA 4 Optional recommended front-
end
122 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
