ZS3-4 Controller Hardware Overview
Slot
Mfg Part
Number
Description Max Note
5 7070195 4-port 1GbE UTP Ethernet 4 Optional recommended front-
end
5 7051223 2-port 10Gb Ethernet Optical
NIC
6 Optional recommended front-
end
5 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or initiator
(backup)
5 7023303 2-port 16Gb FC HBA 4 Optional FC target or initiator
(backup)
6 7070006 2-port 10Gb Ethernet Copper
NIC
4 Optional recommended front-
end
6 375-3696-01 2-port InfiniBand CX2 HCA 4 Optional recommended front-
end
6 7070195 4-port 1Gb Ethernet Copper
UTP NIC
4 Optional recommended front-
end
6 7051223 2-port 10Gb Ethernet Optical
NIC
6 Optional recommended front-
end
6 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or initiator
(backup)
6 7023303 2-port 16Gb FC HBA 4 Optional FC target or initiator
(backup)
7 7067091 4-port (4x4) external HBA 4 Additional optional back-end
7 7070006 2-port 10Gb Ethernet Copper
NIC
4 Optional recommended front-
end
7 371-4325-02 2-port 8Gb FC HBA 4 Optional recommended front-
end
7 375-3696-01 2-port InfiniBand CX2 HCA 4 Optional recommended front-
end
7 7051223 2-port 10Gb Ethernet Optical
NIC
6 Optional recommended front-
end
7 7070195 4-port 1Gb Ethernet Copper
UTP NIC
4 Optional recommended front-
end
7 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or initiator
(backup)
7 7023303 2-port 16Gb FC HBA 4 Optional FC target or initiator
(backup)
8 7067091 4-port (4x4) SAS-2 external
HBA
4 Base configuration
9 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or initiator
(backup)
9 7070006 2-port 10Gb Ethernet Copper
NIC
4 Optional recommended front-
end
Servicing the ZS3-4 Controller 123
