ZS3-4 Controller Hardware Overview
Slot
Mfg Part
Number
Description Max Note
9 7070195 4-port 1Gb Ethernet Copper
UTP NIC
4 Optional recommended front-
end
9 7051223 2-port 10Gb Ethernet Optical
NIC
6 Optional recommended front-
end
9 7023303 2-port 16Gb FC HBA 4 Optional FC target or initiator
(backup)
ZS3-4 NIC/HBA Options - This table describes NIC/HBA PCIe card options for ZS3-4
standalone and cluster configurations.
TABLE 20
ZS3-4 Controller NIC/HBA Options
Mktg Part Number Description
SG-SAS6-INT-Z 8-port 6Gb/s SAS-2 internal HBA
SG-XPCIE2FC-QF8-Z 2-port 8Gb FC HBA
7103791 4-port (4x4) SAS-2 6Gb/s external HBA
7101674 2-port 16Gb FC HBA
7100477 4-port 1Gb Ethernet Copper UTP
7100488 2-port 10Gb Ethernet Copper Base-T
X4242A 2-port InfiniBand CX2 HCA
X1109A-Z 2-port 10GbE SFP+ NIC
X2129A Transceiver 850NM, 1/10GPS, Short Reach, SFP
X5562A-Z Transceiver 10GbE/1GbE, Long Reach, SFP
ZS3-4 PCIe Slot Order - When installing additional PCIe cards to your base configuration,
cards must be added in a specific order.
Note - Slot 0 is always populated with a SAS-2 internal HBA. Slots 1 and 8 are reserved for
4x4 SAS-2 external HBAs.
124 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
