Install the Rackmount Hardware
38 SPARC T5-4 Server Installation Guide • July 2015
Note - An “up” arrow indicates proper orientation.
b.
Secure the adapter bracket in the center hole using one No. 2 Phillips screw.
c.
Insert a cage nut in the hole just above the top of the rack rail bracket.
2.
Repeat the following steps for both the left and right rear mounting points:
a.
Place the adapter bracket in the marked location.
Note - An “up” arrow indicates proper orientation.
