root@orangepi:~# aplay -l
**** List of PLAYBACK Hardware Devices ****
card 0: Codec [H3 Audio Codec], device 0: CDC PCM Codec-0 [CDC PCM Codec-0]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 1: allwinnerhdmi [allwinner-hdmi], device 0: 1c22800.i2s-i2s-hifi i2s-hifi-0
[1c22800.i2s-i2s-hifi i2s-hifi-0]
Subdevices: 1/1
Subdevice #0: subdevice #0
2) HDMI audio playback does not require other settings, just use the aplay command to
play directly
root@orangepi:~# aplay -D hw:1,0 audio.wav
3.18. linux5.4 IR receiving test
1) Install ir-keytable IR test software
root@orangepi:~# apt update
root@orangepi:~# apt-get install ir-keytable
2) Then execute ir-keytable to view the information of the IR device
root@orangepi:~# ir-keytable
Found /sys/class/rc/rc0/ (/dev/input/event5) with:
Name: sunxi-ir
Driver: sunxi-ir, table: rc-empty
lirc device: /dev/lirc0
Supported protocols: other lirc rc-5 rc-5-sz jvc sony nec sanyo mce_kbd rc-6 sharp
xmp
Enabled protocols: lirc
bus: 25, vendor/product: 0001:0001, version: 0x0100
Repeat delay = 500 ms, repeat period = 125 ms
3) An IR remote control needs to be prepared before testing the IR receiving function
