1.4. Hardware Specification
Hardware feature introduction
CPU
Allwinner H3 ARM Cortex-A7 Quad Core
GPU
Mali400MP2 GPU @600MHz
Supports OpenGL ES 2.0
Memory (SDRAM)
1GB DDR3 (shared with GPU
）
Onboard Storage
TF card (Max. 32GB) /8GB eMMC Flash card slot
Onboard Network
10/100 Ethernet RJ45, WIFI Onboard network
Video Input
CSI interface camera
Audio Input
MIC
Video Outputs
HDMI, CVBS
Audio Output
3.5 mm audio port and HDMI
Power Source
DC input, MicroUSB (OTG) cannot be used as power
input
USB 2.0 Ports
3*USB 2.0 HOST, 1*USB 2.0 OTG
Low-level
peripherals
40 pin connector, compatible with Raspberry Pi
Debug serial port
UART-TX,UART-RX,GND
LED
Power led & Status led
Buttons
Power button
（
SW4
）
IR receiver
Support IR remote control
Supported OS
Android,Ubuntu,Debian Image
Interface Definition
Product Size
85mm×56mm
Weight
43g
