3.22. 40 Pin interface pin description
1) Please refer to the figure below for the sequence of the 40 pin pins of the Orange Pi
PC Plus development board
2) The functions of the 40 pin pins of the Orange Pi PC Plus development board are
shown in the table below
GPIO
No.
GPIO
Function
Pin
Pin
Function
GPIO
GPIO No.
3.3v
1
2
5v
