Make sure the transmission is run-
ning with the correct speed and
direction. Wrong speed and/or
direction can damage machinery and
may cause great danger to persons
nearby. The machine is designed for a
PTO-speed of 850 rpm.
Stay clear, rotating machinery.
Strapping point. Lifting point.
Jacking point.
Hydraulics securing valves, locking the tail-
gate lifting cylinders.
Between the tractor and the machine, there is a rotating PTO-shaft.
No one is allowed to stand between the tractor and the machine
while the engine is running. Do not wear loose clothes, scarfs etc.
Warning signs, indicating danger or warning attached to the machine, must not be removed or
painted over. Unreadable signs shall be replaced by new ones. These can be ordered from Orkel
AS.
2.3 EMERGENCY STOP
The machine is equipped with 5 manual emergency stop buttons. Four are accessible from ground level and
one on top of the machine as indicated on Figure 2.1.
Figure 2.1 :
Red circles indicates emergency stop locations. Two more buttons are located on
the opposite side, ground level.
When an emergency stop button has been triggered, the emergency stop button has to be reset so that the
machine can be started from the control panel.
2 SAFETY 16
