8 Lubrication
8.1 Lubrication system, beka max EP 1 76
8.1.1 Oil lubrication, mode of operation 76
8.1.2 Grease lubrication, mode of operation 76
8.1.3 Beka max grease lubrication system 78
8.2 Refilling lubricants 78
8.2.1 Refilling the oil reservoir 78
8.2.2 Adjusting the amount of grease 79
8.2.3 Bleeding the grease system 79
8.3 Electric pump and main distributor 80
8.4 Troubleshooting for Beka max 80
8.5 Oil temperature 81
8.6 Approved lubricants 81
8.6.1 Hydraulics 81
8.6.2 Chain lubrication 81
8.6.3 Greasing 81
8.6.4 Gearbox and gears for hydraulic motors 81
8.7 Manual lubrication charts 82
8.7.1 The compactor 82
8.7.2 Feed hopper 83
8.7.3 Telescopic drawbar 84
8.8 Lubrication list - Manual greasing points 85
8.1 LUBRICATION SYSTEM, BEKA MAX EP 1
The compactor is equipped with a fully automatic lubrication system. It lubricates the chamber roller bush-
ings (grease) and the chains (oil).
8.1.1 Oil lubrication, mode of operation
A single piston pump driven by the hydraulic pressure, supplies oil to the chains through brushes which are
mounted on strategic locations. Each time the chamber door opens, the piston is activated and supplies a
fixed amount of oil to the chains.
8.1.2 Grease lubrication, mode of operation
An electrical motor runs an eccentric disc. The eccentric disc drives two single working pistons which push a
fixed amount of grease through a pressure relief valve, and further on to a main distributor. The main dis-
tributor supplies grease to sub-distributors, which deliver the correct amount of grease to each bearing.
8 LUBRICATION 76
