ORKEL MC850 - 7 Maintenance and Mechanical Adjustments

7 Maintenance and mechanical adjustments
7.1 Safety 55
7.1.1 Before maintenance 55
7.1.2 Safety precautions during maintenance and mechanical adjustments 55
7.1.3 Elements of hazard during maintenance 55
7.1.4 Control after repair or maintenance 56
7.2 Electrics 56
7.3 Wheels 56
7.4 Chains 56
7.4.1 Chain tensioner A 56
7.4.2 Chain tensioner B and C 57
7.5 Feed hopper 58
7.5.1 Tightening the feed hopper belts 58
7.5.2 Ball bearings 59
7.6 Elevator and sub conveyor 59
7.6.1 Conveyor belts and feeder carrier 59
7.6.2 Adjusting the conveyor chains 59
7.6.3 Chain tensioner, sub conveyor 60
7.6.4 Chain tensioner, elevator 61
7.6.5 Ball bearings elevator 61
7.7 Baling chamber 61
7.7.1 Inspection 61
7.7.2 Adjusting the front chamber belt 62
7.7.3 Adjusting the rear chamber belt 62
7.7.4 Adjusting the chamber belt tensioner 65
7.7.5 Replacing chamber belt 66
7.8 Plastic tying unit 66
7.8.1 Control and maintenance 67
7.9 Wrapping table 67
7.9.1 Inspection 67
7.10 Frame, drawbar, attachments 68
7.10.1 Frame 68
7.10.2 Main components, fastening points 68
7.11 Chamber roller bushings 69
7.11.1 Wear inspection 69
7.11.2 Permissible wear 70
7 MAINTENANCE AND MECHANICAL ADJUSTMENTS 54
