Message ID Sensor State
Bale chamber did not open 171 S17 OPEN2
Chamber not closed 180 S18 BALING1, BALEFULL1, NETFEED1, FEEDDELAY1, NETFEED2,
NETFEED3, NET1, PLASTIC0, PLASTIC1, PLASTIC2, PLASTIC3,
PLASTIC4, PLASTIC5, OPENDELAY1, LOAD4, WRAPRAMP, WRAP1,
WRAPSTART, WRAP2, WRAP3, WRAP4, WRAP5, WRAP6, WRAP7
Bale chamber did not close 181 S18 LOAD3
Netknife did not open 190 S19 NETFFED1, NETFEED2, NETFEED3
Feed roll did not open 191 S19 PLASTIC2
Netknife did not close 201 S20 NET1
Feed roll did not open 204 S20 PLASTIC4
Net did not break 202 S20 BSTART01, BSTART05, BSTART10, BSTART15, BALING1,
BALEFULL1
Net tying failure 203 S20 NETFEED3, PLASTIC3
Film cutter did not close 220 S22 PLASTIC5
Emergency STOP 70 S7 (all)
Emergency STOP 230 S23 (all)
Chamber pressure sensor
broken
1 S30 (when baling)
Chamber overpressure 2 S30 (when baling)
Under-voltage at control
unit
3 Control
unit
(all)
Under-voltage at control
unit
4 Control
unit
(all)
Under-voltage at control
unit
5 terminal (all)
Under-voltage at control
unit
6 terminal (all)
Malfunction at control
cable
7 Control
unit
(all) Also malfunction in control box or circuit
Malfunction at control
cable
8 Control
unit
(all) Board error in the electric cabinet
6 CONTROL SYSTEM 53
