ORKEL MC850 - Replacing Chamber Belt; Plastic Tying Unit

7.7.5 Replacing chamber belt
Clean the chamber. Use a high pressure washer.
Remember to secure the chamber door lifting cylinders before entering the chamber
Remove the damaged belt using a knife and cut the belt crosswise. Be observant of the rotation direction.
Hook the new belt to the old one and use the chamber motor to pull the belt into place. Use caution when
using the chamber motor. De-tension the belt before replacing belts. Fit the new belt and insert the locking
rod as shown. Secure the locking rod by mounting the two washers, one on each side
(Figure 7.18).
Figure 7.18 : Belt with locking rod and washer
7.8 PLASTIC TYING UNIT
The tying unit, containing wide film or net is located on top of the chamber.
7 MAINTENANCE AND MECHANICAL ADJUSTMENTS 66
