10.1.2 Ultrasonic Digital sensors
Ultrasonic Digital sensors
ID Description Pin 1 Pin 2
Pin 3
Pin 4 Pin 5
S01 Bale on table KR3-4 KR1-4 KR5-1
S21 Feedhopper KR4-21 KR2-21 KR6-21
10.1.3 Pressure sensors
Pressure sensors
ID Description Pin 1
Pin 2
Pin 3 Pin 4 Pin 5
S30 Chamber pressure KR4-30 KR6-30
10.1.4 Level and high temp/switch
Level and high temp/switch combined in housing
ID Description Pin 1
Pin 2
Pin 3 Pin 4 Pin 5
S26
S27
High temerature swtich
Low level switch KR4-25 KR6-27
KR4-25 KR6-26
10.1.5 Emergency stop switches
Emergency stop switches
ID Description Pin 1 Pin 2 Pin 3
Pin 4
Pin 5
S7,S23 5 switches connected in series KR17-1 KR4-29
10.1.6 Simulate bale on table switch
Simulate bale on table switch
ID Description Pin 1
Pin 2
Pin 3 Pin 4 Pin 5
Bosch switch Momentary switch, NO KR3-2 KR5-1
10.1.7 Safety switch
Safety switch
ID Description Pin 1 Pin 2
Pin 3
Pin 4 Pin 5
S08 2 switches in series. NC KR3-4 KR5-8
10.1.8 Grease pump
Electrical grease pump
ID Description Pin 1 Pin 2
Pin 3
Pin 4 Pin 5
G1 Electrical grease pump KR18-2 KR23-6
10.1.9 Valves
Directional valves, globe valves, proportional valves
ID Description Pin 1 Pin 2
Pin 3
Pin 4 Pin 5
V02 Chamber open KR13-2 KR15-2
V03 Chamber close KR13-3 KR15-3
10 ELECTRICS 88
