5.1.5 Dismantling the machine
General safety precautions must be taken when stripping down the machine. Center of gravity
might change during dismantling. Secure large parts to reduce the risk of injury. Be aware of
overturning.
Hazardous waste like: Oil, plastic and so on, must be stored in an environmentally safe way, or delivered at a
certified waste-disposal plant.
Be aware of overhanging power lines.
Max height in transport position: 3900 mm
5.2 HIGHWAY USE
The compactor is designed for a maximum speed of 40 km/h. Exceeding this speed is considered dan-
gerous. Furthermore, the speed must be limited according to national speed limits. Before using the
machine the operator must ensure that all covers and hatches are closed and secured.
Be aware of overhanging power lines. Max. height in transport position: 3900 mm.
5.2.1 Transport preparation
The levers referred to in this chapter can be found in section 4.2.2 "Lever/Controls overview" and section
4.2.3 "Lever list". For illustrations, see chapter 0.0.1 "Telescopic drawbar and feed hopper F10" in reversed
order.
1. Lift the bale bridge and fold it over the wrapping table.
2. Raise the wrapping table (done from display unit, ) to its upper position in order to ensure free pas-
sage when extending the drawbar.
3. Extend the drawbar (lever 6) until the transport safety lock engages (see section 3.8.1 "Telescopic
drawbar").
4. Fold back the wrapping table belt tensioner.
5. Disconnect the PTO drive shaft and secure it in transport position.
6. Disassemble the covers between the hopper and the elevator.
7. Fold in the hopper side covers, and secure them.
8. Fold the stairs into transport position, according to instructions given in section 4.2.11 "Stairs"
9. Raise the feed hopper (lever 3).
10. Secure the hopper in its upper position by closing the valves M2 and M3 on each side (see ).
11. Retract all four hydraulic jack stands to their upper position (levers 1, 2, 4 and 5).
12. Disconnect hydraulic hoses.
13. Disengage the main power switch.
14. Rotate the wrapping arms to their transport position. See illustration in section 12.6.4 "Dimensional
sketch, transport mode".
15. Move the tractor in front of the machine.
16. Connect the tractor to the draw bar.
17. Connect the el-cable and hoses for hydraulic/pneumatic brakes.
18. Check the road lights and brakes before driving.
19. Ensure that film roller storages, covers and hatches are all closed and secured.
5 TRANSPORT 43
