ORKEL MC850 - Error Messages on Display

Text: Description of parameter setting
Recommended set-
tings/values
Film revolutions Revolutions of film laid on the bale on wrapper table 14 (=6 layers)
First film release First opening of the film cutter 1
Second film release Second opening of the film cutter 4
Third film release Third opening of the film cutter 6 (or 4)
Film cutter open time Operating time from closed to open. 0.5 s
Film cutter close time The time from starting to close the film cutter to finish. 1 - 2 s
Net control Programme setting for machines with net only in the tying unit.
(Stops the machine if net is broken or the roll is empty).
ON
Film control Programme setting for machines with net or film in the tying unit.
(Stops the machine if film/net is broken or the roll is empty)
ON
Net type Type of the net/film wrapping unit - for net only (net) or net/film
model (plastic).
PLASTIC
Measure weight Not in use.
Table down delay Delay of the table from dropping position until it starts to go up
again.
1 - 2 s
Bale rotation delay Extra wrap before rotation starts. (for stabilizing) 0 - 4
Bale rotation time Makes the bale rotate on the table while dropping 0 - 5
Rotate feed-rollers Feed-rollers rotate while opening rollers Yes/no
Bale transport Gives extra oil to the belt under when moving to the table Fast/Normal
6.1.10 Error messages on display
Message ID Sensor State
Bale on the table 10 S1 (not used)
Bale did not move to the
table
11 S1 LOAD1
Table not in middle pos-
ition
30 S3 LOAD3, LOAD4, WRAPRAMP, LOAD5, WRAP1 , WRAPSTART,
WRAP2, WRAP3, WRAP4, WRAP5, WRAP6, WRAP7, BALEREADY1
Table did not move to
middle position
31 S3 LOAD2, DROP3
Wrapper arms not in start
position
50 S5 OPEN1, OPEN2, OPEN3, LOAD1, LOAD2, LOAD3, LOAD5, WRAP1,
WRAP6, WRAP7, BALEREADY1, DROP1, DROP2, DROP3, READY1
No wrap pulse 51 S5 WRAPSTART, WRAP2, WRAP3, WRAP4
Wrapper arm speed to high 52 S5 WRAP3, WRAP4
Wrapper arm obstructed 80 S8 (all states where V9 or V10 drived)
Table did not move to the
down position
90 S9 DROP1
Table did not move to the
up position
100 S10 OPEN1, DROP3
Film broken or roll empty 110 S11 WRAP3, WRAP4
Film broken or roll empty 120 S12 WRAP3, WRAP4
Both films broken or rolls
empty
111 S11, S12 WRAP3, WRAP4
Bale chamber not open 170 S17 LOAD1
6 CONTROL SYSTEM 52
