10 Electrics
10.1 Inputs and outputs sorted by type 87
10.1.1 Inductive sensors 87
10.1.2 Ultrasonic Digital sensors 88
10.1.3 Pressure sensors 88
10.1.4 Level and high temp/switch 88
10.1.5 Emergency stop switches 88
10.1.6 Simulate bale on table switch 88
10.1.7 Safety switch 88
10.1.8 Grease pump 88
10.1.9 Valves 88
10.2 Sensor overview 90
10.3 Sensor list and function 91
10.4 Fuses 91
10.5 Schematics 92
10.5.1 Main board 93
10.5.2 Main board BD1 Left 94
10.5.3 Main board BD1 Right 95
10.5.4 Complete electrical schematics 96
10.1 INPUTS AND OUTPUTS SORTED BY TYPE
10.1.1 Inductive sensors
Inductive sensors
ID Description Pin 1 Pin 2 Pin 3 Pin 4
Pin 5
S03 Table middle position KR3-3 KR1-3 KR5-3
S05 Wrapping arm home position KR3-4 KR1-4 KR5-5
S09 Wrapping arm stop KR3-9 KR1-9 KR5-9
S10 Table lower position KR3-10 KR1-10 KR5-10
S11 Table upper position KR3-4 KR1-4 KR5-11
S12 Film sensor 1 KR3-4 KR1-4 KR5-12
S15 Film sensor 2 KR3-15 KR1-15 KR5-15
S17 Chamber dampening KR4-17 KR2-17 KR6-17
S18 Chamber opened KR4-18 KR2-18 KR6-18
S19 Chamber closed KR4-19 KR2-19 KR6-19
S20 Feed rollers opened KR4-20 KR2-20 KR6-20
S22 Feed rollers closed KR4-22 KR2-22 KR6-22
S31 Net knife closed KR4-31 KR2-31 KR6-31
S32 Chamber speed KR4-32 KR2-32 KR6-32
