ORKEL MC850 - Page 39

Figure 4.3 : Film stretcher with tensioner
Figure 4.4 : Empty film strecher
Threading of the film shall be done as illustrated in the principle drawing
Figure 4.5 : Film in the film stretcher seen from above.
User resources for installing new film rollers may be found at www.orkel.com/qr
4 OPERATION 39
