Table 1. Steering Column-Mounted Controls. - Continued
Key
Control/
Indicator Function
4 Emergency
Flasher Control
Two-position, push/pull switch used to control emergency
flashers. BLACKOUT LIGHTS switch must be in off position
before emergency flashers will operate. Push in switch to
activate emergency flashers. Left and right turn indicators
flash (green) when emergency flashers are engaged.
5 Horn Button Sounds city horn when pressed. Horn is for use in populated
areas.
6 Turn Signal
Lever
Used to operate turn signals. Push turn signal lever up to
signal right turn. Pull turn signal lever down to signal left turn.
Automatically returns to off position when steering wheel is
returned to straight position. Left or right turn indicator flashes
when turn signal is engaged.
7 Steering
Column Lock
Pin
Prevents steering wheel from turning when installed in
steering column.
END OF WORK PACKAGE
TM 9-2320-360-10 0014
0014-3
