OPERATOR MAINTENANCE
TRAILER BRAKES OPERATION
INITIAL SETUP:
Not Applicable
NOTE
•
Model B dash panel shown, Model A dash panel similar.
•
When service brake pedal is pressed, both HET Tractor and trailer
brakes will be applied.
Pull down trailer handbrake control lever (WP 0014) (1) during trailer connect/
disconnect operations, (WP 0034) if required, to apply trailer brakes only.
BLACK
OUT
DRIVE
BLACK
OUT
MARKER
BLACK
OUT
LIGHTS
CHECK
GAUGES
CHECK
ENGINE
AIR
LOW
CROSS COUNTRY
HIGHWAY
MUD SAND & SNOW
9 MAX SPEED 45 MPH)
(MAX SPEED 30 MPH)
( MAX SPEED 15 MPH)
( MAX SPEED 5 MPH)
EMERGENCY
O
VERSPEED
LOW AIR
START
CTI OFF - ON
CTI CONTROLLER MODEL 101
TRAILER
AIR SUPPLY
ENGINE
OFF
ON
START
FILTER MINDER
AIR CLEANER RESTRICTION
RESET
H O
2
—20—
—15—
—10—
— 8 —
PARKING
BRAKE
1
Figure 1.
END OF TASK
END OF WORK PACKAGE
TM 9-2320-360-10 0040
0040-1
