TOW BAR CONNECTION - Continued
WARNING
Utility chains are heavy and difficult to handle. Two personnel are
required when handling utility chains. Failure to comply may result in
serious injury or death to personnel.
29. Manually release spring brakes. (WP 0080)
30. Remove two utility chains (33 and 34) one from each vehicle stowage box with the
aid of an assistant.
9
9
33
2
3
35
36
5
34
1
Figure 8.
TM 9-2320-360-10 0070
0070-8
