ADJUST PASSENGER SEAT - Continued
4
1
2
3
Figure 1.
2. Adjust seat position:
a. Push forward/backward adjustment control (2) to left and slide seat (3) forward
or backward.
b. Release forward/backward adjustment control (2) to lock seat (3) in place.
3. Adjust seat height:
a. Pull height adjustment control (4) up and lift self off seat (3) to raise.
b. Push down on seat (3) to lower.
c. Release height adjustment control (4) to lock seat (3) at desired height.
4. Allow access to/from rear seat:
TM 9-2320-360-10 0060
0060-2
