OPERATOR MAINTENANCE
PERFORM IMMEDIATE ACTION FOR LOSS OF AIR SUPPLY SYSTEM PRESSURE
INITIAL SETUP:
Not Applicable
GENERAL AIR SYSTEM INFORMATION
NOTE
Air pressure shown by the green pointer of AIR PRESS gauge
(WP 0016) indicates air pressure for:
•
Front service brakes.
•
Trailer service brakes.
•
Winch system.
•
HI-LO range valve.
•
Tire inflation connectors.
•
Windshield washer.
•
Horns.
•
Transmission modulator.
•
Driveline lockup.
•
Fan clutch.
NOTE
Air pressure shown by the red pointer of AIR PRESS gauge
(WP 0016) indicates air pressure for:
•
Central tire inflation pressure transducer.
•
Rear tridem spring brakes.
•
Trailer emergency brakes.
•
Rear tridem service brakes.
•
Air suspension.
////////////////////////////////////////////////////////////////////////////////////
TM 9-2320-360-10 0079
0079-1
////////////////////////////////////////////////////////////////////////////////////
////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
