Table 1. Exterior-Mounted Controls and Indicators - Passenger Side. - Continued
Key
Control/
Indicator Function
3 Power Steering
Oil Dipstick
Indicates power steering oil level. Turn dipstick handle
counterclockwise to release from tube and obtain
measurement. Fully insert dipstick into tube and turn handle
clockwise to secure.
4 Swingfire
Arctic Kit Pump
Switch (if
equipped)
When installed, two-position switch used to control coolant
pump operation.
5 Passenger
Side Fuel
Shutoff Valve
Isolates driver side and passenger side fuel tanks. Should be
closed only when required by maintenance procedures.
Should be open all other times.
END OF WORK PACKAGE
TM 9-2320-360-10 0025
0025-3
