Table 1. Winch Station Controls and Indicators. - Continued
Key
Control/
Indicator Function
8 CABLE HOLD
DOWN Control
Used to engage and disengage cable tensioner on main
winches. Control is OFF when paying out winch cable with
auxiliary winch. Control is ON when reeling in winch cable to
ensure cable spools properly onto drum
9 PASSENGER
SIDE WINCH
KICKOUT
Control
Used to engage and disengage passenger side winch
kickout. When disengaged, winch drum will spool freely and
cable can be payed out using auxiliary winch. When engaged,
winch operation is controlled from PASSENGER SIDE
WINCH control.
10 ENGINE
SPEED
CONTROL
Switches
Two switches used to control speed of engine during winch
operations. When left switch is set to LOW ENGINE IDLE,
engine operates at low rpm. When left switch is set to HIGH
ENGINE IDLE and PUSH TO LOCK ENGINE @ HIGH IDLE
switch is pressed, engine operates at high rpm.
11 WINCH
SPEED
CONTROL
Switch
Two-position (LOW/HIGH) switch used to control pay out/reel
in speed of main winches.
12 DRIVER SIDE
WINCH
KICKOUT
Control
Used to engage and disengage driver side winch kickout.
When disengaged, winch drum will spool freely and cable can
be payed out using auxiliary winch. When engaged, winch
operation is controlled from DRIVER SIDE WINCH control.
END OF WORK PACKAGE
TM 9-2320-360-10 0022
0022-4
