NOTE
Seat belt does not have self-adjusting lock. Pull shoulder belt to take out
slack from lap belt.
3. Pull shoulder belt (4) until lap belt (3) fits snug.
4. Adjust shoulder belt (4) with no more than 1 in. (2.5 cm) slack between chest and
shoulder belt (4).
5. Lift up release lever (5) of comfort latch (6) to clamp shoulder belt (4) in place.
6. Pull down on shoulder belt (4) to release lever (5) of comfort latch (6).
7. Push down on red button (7) to release lap belt (3). Pull out seat belt flat metal end
(1).
END OF TASK
END OF WORK PACKAGE
TM 9-2320-360-10 0059
0059-2
