The product must be sufficiently secured during transport in vehicles for transporting persons with reduced mobil
ity. The illustrations that follow show an example for anchoring in a motor vehicle.
The manufacturer is not responsible for the fastening systems that are used. Ensure that only fastening systems
that meet the applicable legal requirements and are designed for the overall weight of the product including the
user are used.
The transport weight of the person to be transported in a vehicle for transporting persons with reduced mobility
corresponds to the maximum permissible user weight (see page117).
7.18.1 Required accessories
Additional accessories must be installed to use the power wheelchair as a seat in a vehicle for transporting per
sons with reduced mobility. The qualified personnel who fitted the wheelchair can provide more information.
Securing the product with attachment straps
The following sets for a vehicle for transporting persons with reduced mobility are available for securing with
attachment straps:
• Standard seat: 491S75=ST655
• Standard seat with 20° power seat tilt: 491S75=ST658
• VAS seat: 491S75=ST656
• VAS seat with power back support angle adjustment: 491S75=ST657
Securing the product with the Dahl docking system
Securing with the optional Dahl docking system requires the Ottobock mounting kit for the Dahl docking system:
• Standard seat: 491S75=ST610
• VAS seat: 491S75=ST615
The corresponding adaptation set from Dahl and other components from the Dahl basic kit are also required. Fur
ther information is available from Dahl Engineering ApS, e-mail: dahl@dahlengineering.dk, Internet: https://dahlen
gineering.dk/en/.
7.18.2 Using the product in a vehicle
WARNING
Positioning in vehicles for transporting persons with reduced mobility
Serious injuries in case of accidents due to user error
► Positioning of the product in vehicles for transporting persons with reduced mobility may only be performed
by the qualified personnel.
► The product must always face forwards when it is used as a seat in a vehicle for transporting persons with
reduced mobility.
► Instruct the qualified personnel regarding the mounting points on your product described below.
WARNING
Inadequate transportation safety
Loss of safe restraint due to failure to observe transportation instructions
► Observe the following instructions for correct transport safety in the vehicle for transporting persons with
reduced mobility.
► If necessary, instruct the qualified personnel on the following information.
Securing the product in the vehicle for transporting persons with reduced mobility
The wheelchair is secured in the vehicle for transporting persons with reduced mobility with the help of the fixation
kit. The fixation points are marked with stickers. The stickers indicate where the user has to engage the hooks of
the safety belt system:
100
Use
490E75=1_C
