USER'S MANUAL
General instructions for use
I-Max Touch (110-120V) (Rev. 0)
32
This key displays the acquired image
stored in the memory of the unit; the
main menu area is replaced by the
image.
View image
This key is used to return to the control
panel (main menu) when an acquired
image is displayed.
Return Main Menu
The Pen Drive key appears when a pen
drive (memory stick) is inserted in the
USB connector of the control panel; it
writes the acquired image that is stored
in the memory of the unit on the pen
drive that is inserted.
When this key is green, the pen drive is
recognised, has enough free space and
is ready for use.
When the key is orange, it is busy; the
image is being written on the pen drive.
When the key is red, the pen drive does
not have enough free space on it, or it
is not recognised.
Full/error
In operation
Ready for use
When the acquired image is displayed
on the control panel screen, it is
possible to zoom in and out of the
image using these two keys.
Zoom in
Zoom out
To Next Page
