USER'S MANUAL
General instructions for use
I-Max Touch (110-120V) (Rev. 0)
58
6.6.1 Preparation of the device
To select the TMJ examination, press key "Examination Mode Selection"
(10) until the following message and graphic is displayed:
x x k V x x m A 9 . 7 0 s
T M J O / C - > C L O S E
The system is positioned in the following configuration:
• ADULT with the display of the corresponding graphic in the button
• MEDIUM SIZE with the display of the corresponding graphic in the
button
and the display showing the default exposure parameters (if this is the
first TMJ exposure), or the exposure parameters (kV and mA) of the last
exposure performed. For example:
7 2 k V 0 6 m A 9 . 7 0 s
T M J O / C - > C L O S E
Once the settings have been completed, the chin support must be placed
in position if it has been removed (see paragraph 6.4).
NOTE:
The I-Max Touch is based on a standard dentition and ascending rami
shape.
This shape, based on statistical data, establishes a standard shape for
the dentomaxillofacial complex, defining also the position and the
direction of the condyles. The patient anatomy can differ significantly
from the statistical model; based on his experience and competence, the
user has to judge this variation.
IN ANY CASE, THE RADIOGRAPHY IMAGES CANNOT BE USED TO
PERFORM CALCULATIONS OF DISTANCES, ANGLES ETC.
*
