USER'S MANUAL
General instructions for use
(Rev. 0) I-Max Touch (110-120V)
91
6.9 Examination to assess bone growth (Carpus)
The cephalometric device can also be used to carry out X-rays to evaluate
the state of calcification and bone growth, X-raying the hand/wrist
complex to obtain an X-ray that contains the anatomic details necessary
to evaluate the patient's bone growth trend.
The image format set in order to carry out this examination is 18x22
Symmetric, not adjustable; it is therefore necessary to position the
auricular rods and the nose-rest as for the cephalometric Antero-
Posterior examination, so that these elements do not interfere with the
X-ray trajectory. Refer to Figure 16.
