6.2.2 Release of the sensor from the sensor holder
The operations for releasing the sensor from the relative sensor holder
are specular to the ones described for the hooking of the same.
1. Grip the sensor by the appropriate handgrip; close the fingers to form
a fist, by engaging the control lever and bring it to the position where
the same disappears inside the handgrip, so that the whole mobile
system retracts and the electronic connectors and the reference plugs
are completely released.
2. Grip firmly the handgrip, and move towards the upper part of the
digital sensor, in order to free the mobile part from the hooking
system.
3. By keeping the sensor with the upper part parallel to the relative
horizontal part, carry out a horizontal movement in order to free the
protruding part of the sensor from the relative casing of the sensor
holder, disengaging thus the hooking system.
4. Always gripping firmly the sensor, in order to avoid accidental falls, it
is possible to freely move the sensor to the desired position.
