6.5.1 Preparation of the device
When the unit is switched on, the Panoramic Examination is selected as
standard. If the operator has previously made another kind of
examination to select Panoramic use the key "Examination Mode
Selection" (10) .
By doing so, it is possible to modify the type of examination between STD
PANORAMIC, TMJ O/C, SINUS, CEPH; such variation takes place with
continuous rotation, therefore, to move from the TMJ O/C mode to the
STD PANORAMIC the key needs to be pressed 3 times.
After selection Panoramic, the system positions itself with the following
configuration:
• ADULT with the display of the corresponding graphic in the button
• MEDIUM SIZE with the display of the corresponding graphic in the
button
• STANDARD DENTITION with the display of the corresponding
graphic in the button
and the display and graphic showing the default exposure parameters (if
this is the first panoramic exposure), or the exposure parameters (kV and
mA) of the last exposure performed. For example:
7 2 k V 0 6 m A 1 3 . 8 s
P A N O R A M I C - S T D
Once the settings have been completed, the chin support must be placed
in position.
The key "Examination Mode Selection" (10) enables the selection of
specific submodes, selectable by means of the keys "Arrow right" (12) and
"Arrow left" (11), enabling the sliding in one direction or another.
Previous examination Next examination
For the Panoramic examination, the following selections are possible:
STD Panoramic -> Right Emi-panoramic -> Left Emi-panoramic ->
Reduced dose Panoramic -> Improved orthogonality dentition -> Frontal
dentition -> STD Panoramic.
This selection is cyclic, so pressing the button repeatedly will change the
selected mode.
